Custom PCB Assembly

  • High Precision Custom PCB Assembly suppliers

Custom PCB Assembly.


1. Introduction


We produce full assembly PCB circuit boards according to customer's design (Gerber File & BOM list). Including PCB production, component sourcing, and SMT/DIP.


We has state-of-the-art assembly plants that allow us to follow your project through every step of the assembly process. We handle all types of pcb assembly, from basic thru hole PCB assembly to standard surface mount PCB assembly to ultra-fine pitch BGA assembly. Our engineers work with customers from across all fields including telecommunications, aviation, consumer electronics, wireless, medial, automotive and instrumentation.



2. Capavity


SMT Position accuracy:20 um
Components size:0.4×0.2mm(01005) —130×79mm,Flip-CHIP,QFP,BGA,POP
Max. component height::25mm
Max. PCB size:680×500mm
Min. PCB size:no limited
PCB thickness:0.3 to 6mm
PCB weight:3KG
Wave-Solder Max. PCB width:450mm
Min. PCB width: no limited
Component height:Top 120mm/Bot 15mm
Sweat-Solder Metal type :part, whole, inlay, sidestep
Metal material:Copper , Aluminum
Surface Finish:plating Au, plating sliver , plating Sn
Air bladder rate:less than20%
Press-fit Press range:0-50KN
Max. PCB size:800X600mm
Testing ICT,Probe flying,burn-in,function test,temperature cycling

94v0 UL Rohs FR4 Blue Soldmask Printed Circuit Board Assembly PCBA

94v0 UL Rohs FR4 Blue Soldmask Printed Circuit Board Assembly PCBA
94v0 UL Rohs FR4 Blue Soldmask Printed Circuit Board Assembly PCBA

Large Image :  94v0 UL Rohs FR4 Blue Soldmask Printed Circuit Board Assembly PCBA

Product Details:

Place of Origin: China
Brand Name: OEM ODM
Certification: UL,ROHS, REACH,TS16949
Model Number: PCBA-J-088

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: To be inquired
Delivery Time: 15-18working days
Payment Terms: T/T, L/C
Supply Ability: 10000pcs/month
Detailed Product Description
System: Android 5.1 Memory: 1G+8G/2G+16G
3GWCDMA: 850/1900/2100MHz HD: 1280X720
Camera: 2MP+8MP Vidio: Decode:1080p 30fps Encode:1080p 30fps
Wifi: WiFi: 802.11b/g/n
High Light:

double sided pcb


quick turn pcb assembly

94v0 UL Rohs FR4 Printed circuit board assembly
Platform: MTK6580 quad-core A7 1.3G
Operating system: Android 5.1
Memory: 1G + 8G / 2G + 16G
Network standard: 2GGSM: 850/900/1800 / 1900MHz four bands
3GWCDMA: 850/1900 / 2100MHz
Resolution: HD: 1280X720
Camera: Front 2MP, rear 8MP
Video: Decode: 1080p 30fps Encode: 1080p 30fps
Bluetooth: BT4.0
WiFi: 802.11b / g / n
FM: FM radio
Positioning navigation: A-GPS / GPS
Power Management: Contains ChargerIC, 4.2VLi-ion / Li-Poly, morethan1.2A
Data interface: including LCM, Camera, USB, UART, I2C, SPI, I2S, ADC, Keypad, GPIOS and so on.
Expansion module: including NFC, one-dimensional two-dimensional scanning, RFID, fingerprint, credit card, identification, infrared, OBD and so on.
Application areas: widely used in intelligent three anti-mobile phone / tablet, handheld terminal, identification, intelligent vehicle and other industry application design and other fields.
Navigation: built-in GPS navigation module, satellite positioning. From this phone navigation no longer spend money
Chip: using MTK6572 dual-core processor, 512M running memory, faster, more stable
Camera: built-in 800W pixel rear camera, 200W pixel front camera. Support face recognition, smiling face, more fun
Screen: 960 * 540 resolution 4.5-inch high-definition display
System: the most fashionable Andrews system, version 4.4.2, running more stable and smoother
Network: dual card dual standby, support mobile 2G network, Unicom 2G network, China Unicom 3G network, does not support telecommunications
Appearance: high-density engineering materials, wear-resistant, non-slip, high-end technology, domineering
Other: support picture in picture, WIFI, Bluetooth, FM, 3G Internet, games, music, e-books, massive software, unlimited downloads
What KAZ Circuit can do for you:

  • PCB manufacturing (prototype, small to medium, mass production)
  • Components Sourcing
  • PCB Assembly/SMT/DIP

To get a full quotation of the PCB/PCBA, pls provide the information as below:

  • Gerber File, with detail specification of the PCB
  • BOM List (Better with excel fomart)
  • Photoes of the PCBA (If you have done this PCBA before)

Company Informaiton:
KAZ Circuit is a professional PCB manufacturer from China since 2007, also provide PCB Assembly service for our customers. Now with about 300 employees. Certified with ISO9001,TS16949, UL, RoHS. We are confident to provide you quality products with factory-directed price within the fastest delivery time!
Manufacturer Capacity:

Capacity Double Sided: 12000 sq.m / month
Multilayers: 8000sq.m / month
Min Line Width/Gap 4/4 mil (1mil=0.0254mm)
Board Thickness 0.3~4.0mm
Layers 1~20 layers
Material FR-4, Aluminum, PI
Copper Thickness 0.5~4oz
Material Tg Tg140~Tg170
Max PCB Size 600*1200mm
Min Hole Size 0.2mm (+/- 0.025)
Surface Treatment HASL, ENIG, OSP

SMT Capacity
