Automotive PCB: Printed Circuit Boards for Automotive products. With TS16949 certificated.
PCBs for the Automotive industry require high reliability, long life service, at a highly competitive rate. The sector consists of passenger vehicles, trucks, trailers, sub assemblies, and dealer support systems.
Amitron provides printed circuit boards that offer a wide range of materials, composites, and construction, that perform well in the rigors of the automotive world. We produce display PCBs, circuits for engines and various electronic components such as stereo systems.
High Temperature laminates, copper and aluminum substrates perform very well in harsh automotive applications. Amitron supplies a vast array of laminates with copper weights that are unrivaled in our industry. Differential copper plated is unique to Amitron. Twenty ounce copper on side one and one ounce copper on side two would be a typical configuration of differential copper. This technique offers signal application on one side and high power on the other. Amitron is ISO 9001-2008 certified.
2. Applications
Product Details:
Payment & Shipping Terms:
|
| Layers: | 2 | Material: | FR-4 |
|---|---|---|---|
| Board Thickness: | 1.6mm | Copper: | 1oz |
| Surface: | ENIG | Size: | 138.5*160mm / 25UP |
| High Light: | 94v 0 circuit board,ENIG Surface HDI PCB Board,FR4 HDI PCB Board |
||
This is a Double sided PCB with 1.6mm 1oz copper thickness HASL surface treatment white soldmask
How to place an order:
More information about KAZ:
Manufacturing Capacity - Rigid PCB
| Item | Production Capacity |
| Type of Products | Single Sided, double sided & multilayer |
| Max Board Size | Single & Double Sided: 600*1500mm |
| Multilayer: 600*1,200 mm | |
| Surface Finish | HASL, ENIG, OSP, Immersion Silver, Golden Finger, etc. |
| Layers | 1~20 |
| Boad Thickness | 0.4~4.0mm |
| Base Copper | 18um(1/2oz), 35um (1oz), 70um (2oz), 105um (3oz), 150um (4oz), 300um (8oz) |
| Board Material | FR-4, Aluminum base, Polymide, copper base, ceramic base |
| Min Drilling Hole Size | 0.1mm |
| Min Line Width & Space | 0.075mm |
| Platting Gold | Nickle Plating Thickness 2.5~5um, gold thickness 0.05~0.1um |
| Tin Spraying | Tin thickness 2.5~5um |
| Milling Space | wire & edge: 0.15mm, hole & edge: 0.2mm, Contour Tolerance: +/-0.1mm |
| Socket Chamfer | Angle: 30°/45°/60° Depth: 1~3mm |
| V-Cut | Angle: 30°/45°/60° Depth: 1/3 of board thickness, min aise: 80*80mm |
| On-Off Test | Max Testing Area: 400*1,200mm |
| Max Testing Point: 12,000 points | |
| Max Testing Voltage: 300V | |
| Max Insulation Resistance: 100mΩ | |
| Impedance Control Tolerance | ± 10% |
| Soldering Endurance | 85℃~105℃ / 280℃~360℃ |
