PCB Board For LED

  • High Precision PCB Board For LED suppliers

Led Light PCB Board:PCB for LED light.


Mainly Aluminum and FR-4 material. Mainly used for panel light, wallwasher light, emergency light, LED Tube, dashboard background light, high bay light, flood light or project lamp, etc.


The main purpose of using an aluminum substrate is that it has good heat dissipation. Because of the large heat generation of high-power LEDs, most of the aluminum substrates are used for the production of LED lighting fixtures. FR-4 fiberglass circuit board is a traditional electronic product circuit board. It has a wide range of applications due to its good insulation, corrosion resistance, pressure resistance and multi-layer printing.
The product quality of the LED aluminum substrate is mainly considered to be the material type, hardness, surface and thickness of the aluminum material, and it is also necessary to select a suitable model size according to the heat generation amount of the product. FR-4 glass fiber circuit board is a relatively mature product, and many of the LED display screens are made of FR-4 glass fiber circuit board.

High Power Led Aluminium Pcb Board Double Sided

High Power Led Aluminium Pcb Board Double Sided
High Power Led Aluminium Pcb Board Double Sided High Power Led Aluminium Pcb Board Double Sided High Power Led Aluminium Pcb Board Double Sided

Large Image :  High Power Led Aluminium Pcb Board Double Sided

Product Details:

Place of Origin: China
Brand Name: KAZ
Certification: UL,ROHS
Model Number: KAZA-001

Payment & Shipping Terms:

Minimum Order Quantity: 1 Unit
Price: 0.1~10
Packaging Details: vacuum package
Delivery Time: 2 to 8 work days
Payment Terms: T/T, Western Union, MoneyGram, L/C, D/P
Supply Ability: 20000 m2 per month
Detailed Product Description
Material: 5052 / 6061 Aluminum Ink: TAIYO INK
Copper Thickness: 2 OZ Layer Count: 2
Color: White Lead Time: 2 To 8 Work Days
High Light:

aluminium pcb board


led light circuit board

  • Specifications:
    • Material: aluminum
    • Layer count: 2 layers
    • Board thickness: 1.6mm
    • Copper thickness: 1oz
    • Minimum drill size: 0.3mm
    • Minimum trace & gap: 0.3mm
    • Surface finish: HAL lead free
    • Special technology: aluminum material in the middle, with plated through holes
    • Applications:LEDs


   . Description :


Layer: 1 layer-30 layers
Board thickness: 0.2mm-6.0mm
Copper thickness: 0.5oz-6.0 oz
Max board size : 600 x 1200mm
Min. hole diameter: 0.1mm
Min. line width: 0.075mm
file format: pcb,doc,ddb etc
MOQ: 1 piece
Base material: FR-4,TG, CEM-1, CEM-3, Aluminium,94V0, 94HB
Solder mask & Silkscreen: green, red, blue, yellow, black, white etc
Surface finish: ENIG, ImAg, ImSn, OSP, HASL, lead free,immersion gold,Gold-plate etc


  .  Pictures :


High Power Led Aluminium Pcb Board Double Sided



High Power Led Aluminium Pcb Board Double Sided
